1817858150DB

ICON Alloys Rebound HD, Double Black, 17 x 8.5 / 8 x 170, 6mm Offset, 5" BS

Product Details

Bring a bold new look and incredible strength to your 8-lug pickup with the ICON Alloys REBOUND HD! Combining sharp lines, a concave spoke design, and "ICON-optimized" dimensions, these wheels will increase both the form and function of your 3/4-ton truck. Staying true to the ICON Alloys approach, the REBOUND has been engineered to maximize caliper clearance and optimize wheel position for un-hindered suspension travel and steering function. Backspace dimensions and wheel offset have been strategically developed to reduce scrub radius, improving all-around handling and ride quality and making a set of these wheels the perfect complement to an ICON Vehicle Dynamics suspension system.

Built specifically for HD applications, with a 4,000LB load rating
Application-specific dimensions optimize vehicle dynamics and tire clearance
Reduced unsprung weight and rotating mass improves on and off-road vehicle performance
Aluminum alloy construction provides strength properties that are well suited for off-road use

Technical Notes

TECH NOTE: Professional mounting and balancing of an appropriately sized tire prior to installation onto vehicle is recommended.

Warranty Information

Warranty information unavailable

Compatible Make / Model

Specification

Brand	ICON Alloys
Prop65 Warning	WARNING: This product contains chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm.
Technical Notes	TECH NOTE: Professional mounting and balancing of an appropriately sized tire prior to installation onto vehicle is recommended.
UPC	00840103429373
Material	Aluminum
Finish	Powdercoated
Color	Double Black
Construction	Cast
Backspacing	5
Bolt Pattern	8 X 170
Center Cap Included	Yes
Diameter	17
Inside Diameter	125
Lug Hole Diameter	1.1
Lug Nut Seat Type	Conical
Maximum Load Rating	4000
Offset	6
Positive Offset	6
TPMS Compatible	yes
Width	8.5
Wheel Nuts Included	No
TPMS Included	No
Width	19.00 in
Length	20.00 in
Depth	10.00 in
Weight	30.0000 lb
