Brand |
ICON Vehicle Dynamics |
Prop65 Warning |
WARNING: This product contains chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm. |
Technical Notes |
- OEM Wheels & Tires Fitment (With Sasquatch Package): Yes
- APPLICATION NOTE #24: Factory UCA's will not align properly past 2.5” of lift. Above 2.5” of lift an aftermarket UCA is recommended.
- APPLICATION NOTE #55: Shocks are fully serviceable. Coilover heights indicated are for a stock equipped vehicle
- APPLICATION NOTE #132: When running 37" tires use up travel limiters part #611075 in the front
- APPLICATION NOTE #138: Recommended crash bars part #42000 on Non-Sasquatch equipped vehicles when running 35" tires
- APPLICATION NOTE #139: When running 37" tires crash bar removal may be required but is not recommended
- TECH NOTE: Due to increased wheel travel and lift height provided by these coilovers, ICON upper control arms with Delta Joint Pro, part numbers 48400DJ or 48500DJ, are recommended. Other aftermarket front upper control arms may not be compatible and it is the duty of the installer to verify fitment. Failure to cycle suspension and check for ball joint bind issues may lead to component failure and/or injury.
- TECH NOTE: Fitment testing done with ICON & OE steering components. Due to tight clearances to front coilovers, certain aftermarket steering components may not be compatible.
- TECH NOTE: Bronco Everglades will have lift height range of 1.5-2.5" over stock
- TECH NOTE: Not compatible with Bronco Raptor
- OEM Wheels & Tires Fitment (Without Sasquatch Package): No
- Recommended Aftermarket Wheels (With Sasquatch Package): ICON Alloys - 17x8.5" w/ 4.75" Backspace / 0mm Offset
- Recommended Aftermarket Wheels (With Sasquatch Package): ICON Alloys - 18x9" w/ 5.00" Backspace / 0mm Offset
- Recommended Aftermarket Wheels (With Sasquatch Package): ICON Alloys - 20x9" w/ 5.00" Backspace / 0mm Offset
- Recommended Aftermarket Wheels (Without Sasquatch Package): ICON Alloys - 17x8.5" w/ 5.75" Backspace / 25mm Offset
- Recommended Aftermarket Wheels (Without Sasquatch Package): ICON Alloys - 18x9" w/ 6.00" Backspace / 25mm Offset
- Recommended Aftermarket Tires (With Sasquatch Package): 35" x 12.50" (37" tires require coilover bump stop spacers along with minor trimming)
- Recommended Aftermarket Tires (Without Sasquatch Package): 35" x 12.50" (Recommend high clearance crash bars part number 42000, 37" tires require coilover bump stop spacers along with trimming and modifications)
|
UPC |
00840103412351 |
Maximum Lift |
4 |
Material |
Aluminum |
Body Diameter |
2.5 |
Remote Reservoir |
NO |
Adjustable Height |
Yes |
Spring Rate Type |
Linear |
Spring Color |
Black |
Adjustable Damping |
NO |
Shaft Diameter |
0.875 |
Cylinder Color |
Silver |
Cylinder Material |
Steel |
Service Parts |
252010 - 2.5 IFP REBUILD KIT |
Add-On Part |
611075 - C/O BUMP STOP SPACER KIT 7/8" SHAFT 1/2" TALL |
OEM Wheels & Tires Fitment |
Yes |
Recommended Aftermarket Tires |
(Without Sasquatch Package): 35" x 12.50" (Recommend high clearance crash bars part number 42000, 37" tires require coilover bump stop spacers along with trimming and modifications) |
Recommended Aftermarket Wheels |
(With Sasquatch Package): ICON Alloys - 20x9" w/ 5" Backspace / 0mm Offset |
Minimum Lift |
1.5 |
Width |
13.00 in |
Length |
31.00 in |
Depth |
7.00 in |
Weight |
55.0000 lb |
