51213

ICON 2024 Toyota Tacoma, Rear, .5" Lift, Triple Rate Coil Spring Kit

Product Details

ICON Triple Rate rear coil springs for 2024 Toyota Tacoma provide a modest increase in ground clearance while greatly enhancing on- and off-road performance, especially when used with ICON shocks and suspension components. The triple-rate coil design provides softer droop and ride rates with a firmer overload rate that combine to deliver on-road comfort with excellent bottoming resistance and superior off-road performance while providing .5" of rear lift over stock. Like all ICON coil springs, they feature a lifetime guarantee against sagging/breakage allow you to drive with confidence in knowing that you have the best suspension products available for the 2024 Toyota Tacoma.

.5" rear lift height over stock
Triple rate rear coil springs with ICON-engineered droop, ride, and overload rates
Significantly improves on- and off-road ride quality and performance over stock
Dual stage powder coating for corrosion resistance
Lifetime guarantee against sagging/breakage

Technical Notes

Factory Wheels & Tires Fitment: Yes
Recommended Aftermarket Wheels: ICON Alloys - 17" x 8.5" with 5.75" Backspace / 25mm Offset
Recommended Aftermarket Wheels: ICON Alloys - 18" x 9" with 6" Backspace / 25mm Offset
Recommended Aftermarket Tires: 33" x 11.50" (Larger tires may fit but fender trimming and modifications will be required.)
APPLICATION NOTE #85: Advertised lift height ranges are for a stock equipped vehicle. Increasing weight of vehicle due to accessories will alter lift range.
APPLICATION NOTE #164: Will not fit Tacoma submodels equipped with rear leaf springs

Warranty Information

Warranty information unavailable

Compatible Make / Model

Toyota Tacoma (2024-2024)

Specification

Brand	ICON Vehicle Dynamics
Prop65 Warning	WARNING: This product contains chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm.
Technical Notes	Factory Wheels & Tires Fitment: Yes Recommended Aftermarket Wheels: ICON Alloys - 17" x 8.5" with 5.75" Backspace / 25mm Offset Recommended Aftermarket Wheels: ICON Alloys - 18" x 9" with 6" Backspace / 25mm Offset Recommended Aftermarket Tires: 33" x 11.50" (Larger tires may fit but fender trimming and modifications will be required.) APPLICATION NOTE #85: Advertised lift height ranges are for a stock equipped vehicle. Increasing weight of vehicle due to accessories will alter lift range. APPLICATION NOTE #164: Will not fit Tacoma submodels equipped with rear leaf springs
UPC	00840103428765
Material	Steel
Finish	Powdercoated
Maximum Lift Height	0.5
Rear Spring Rate Type	Progressive Triple Rate
Spring Color	Black
OEM Wheels & Tires Fitment	Yes
Recommended Aftermarket Tires	33" x 11.50" (Larger Tires May Fit but Fender Trimming and Modifications will be Required)
Width	14.00 in
Length	22.00 in
Depth	8.00 in
Weight	40.0000 lb
