Brand |
ICON Vehicle Dynamics |
Prop65 Warning |
WARNING: This product contains chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm. |
Technical Notes |
- Factory Wheels & Tires Fitment: Yes
- TECH NOTE: Models equipped with PowerBoost hybrid engines will have lift height range of 0-2.75" over stock
- TECH NOTE: Models equipped with Power-Stroke diesel engines will have lift height range of 0-2.5" over stock
- TECH NOTE: Not compatible with models equipped with BlueCruise
- Recommended Aftermarket Wheels: ICON Alloys - 17x8.5" w/ 5” Backspace / 6mm Offset
- Recommended Aftermarket Wheels: ICON Alloys - 18x9" w/ 5.25" Backspace / 6mm Offset
- Recommended Aftermarket Wheels: ICON Alloys - 20x9" w/ 5.625" Backspace / 16mm Offset
- Recommended Aftermarket Tires: 33" x 11.50" (Larger Tires May Fit but Fender Trimming and Modifications will be Required)
- APPLICATION NOTE #55: Shocks are fully serviceable. Lift heights indicated are for a stock equipped vehicle.
- APPLICATION NOTE #129: Will not work with factory installed electronically controlled suspension.
- APPLICATION NOTE #179: Only compatible with stock or original ICON Delta Joint UCAs. Not compatible with ICON Delta Joint Pro UCAs.
- TECH NOTE: Only compatible with rear-wheel drive (2WD) models
|
UPC |
00840103411545 |
Adjustable |
No |
Maximum Lift |
3 |
Material |
Steel |
Body Diameter |
2.5 |
Remote Reservoir |
NO |
Adjustable Height |
yes |
Spring Rate Type |
Linear |
Spring Color |
Black |
Adjustable Damping |
NO |
Shaft Diameter |
0.875 |
Cylinder Color |
Silver |
Cylinder Material |
Steel |
Service Parts |
252002 - UNIVERSAL SPANNER WRENCH (2.0/2.5/3.0) |
Add-On Part |
198000 - 2 PIN COILOVER SPANNER WRENCH KIT |
OEM Wheels & Tires Fitment |
Yes |
Recommended Aftermarket Tires |
33" x 11.50" (Larger Tires May Fit but Fender Trimming and Modifications will be Required) |
Recommended Aftermarket Wheels |
ICON Alloys - 20x9" w/ 5.625" Backspace / 16mm Offset |
Width |
13.00 in |
Length |
26.00 in |
Depth |
7.00 in |
Weight |
53.0000 lb |
