Yukon 1541H alloy front left hand short side stub axle for GM 9.25" IFS ('88-newer) See Notes | YA G26009627 | RANDYS Worldwide

Yukon 1541H alloy front LH short side stub axle, '88-up GM 9.25" IFS, see notes

Product Details

Yukon Gear & Axle offers an extensive line of general replacement and high-performance axles for passenger car, truck and SUV applications. High quality alloys and the latest in heat-treating technologies provide a stronger-than-stock axle for off-road, on the street, or at the track.

Fits 1988 and up GM 9.25" IFS
Left hand side
33 spline

Technical Notes

Fits 2007 and newer clamshell applications, will also work for 4WD/ AWD 2006 & older applications when used with YPKGM9.25IFS-S-33 internal gear kit. The snap ring location is 16.99 mm from the end of the splines for 2007+ applications. The snap ring location is 13.8 mm from the end of the splines for the 2006 and down axle

Warranty Information

Warranty information unavailable

Compatible Make / Model

Compatible Differentials

GM 9.25" IFS Front, '10 & down

Specification

Upsell	YESAXLE
Brand	Yukon Gear & Axle
Prop65 Warning	Not Applicable
Keywords	07,07,10,6,9.25IFS,9.25IFS,AX:GM9.25IFS-SHORT,AXLE,AXLE,BOLT,CLAMSHELL,CLAMSHELL,DIFFSTUBGM925,FLANGE,FRONT,FRONT,GM,GM,GM40057071,IFS,LEFT,LEFT,LH,SHAFT,SHAFT,SHORT,SHORT,SIDE,SIDE,STUB,STUB,UP,YA,YA
Technical Notes	Fits 2007 and newer clamshell applications, will also work for 4WD/ AWD 2006 & older applications when used with YPKGM9.25IFS-S-33 internal gear kit. The snap ring location is 16.99 mm from the end of the splines for 2007+ applications. The snap ring location is 13.8 mm from the end of the splines for the 2006 and down axle
UPC	883584215905
ProxyNumber	21590
Width	12.00 in
Length	5.00 in
Depth	5.00 in
Weight	5.1500 lb
